2001-2003 ECM 89661-48410 for Toyota Highlander A/T 3.0L V6 2WD

2001-2003 ECM 89661-48410 for Toyota Highlander A/T 3.0L V6 2WD

Name: 2001-2003 ECM 89661-48410 for Toyota Highlander A/T 3.0L V6 2WD
Brand: Toyota
SKU: 89661-48410
Availability: InStock

$234.94

Includes a warranty of 1 year !

Secure Checkout

SSL Enabled Secure Checkout

Fast ShippingAll products and services ship between 1 and 10 business days. This depends on the Lead Time, which is specified and described further below in the Lead Time area in the ? icon.

We use FedEx and USPS.

Only 1 available!

Brand: Toyota
Condition: Refurbished
Units Sold: 7
Warranty: 1 year

SKU: 89661-48410
MPN: 89661-48410

Lead Time: 7 business days

When you order this product, the "Lead Time" is the maximum time in business days that takes us before the product is actually shipped to you. This includes everything that applies, like transferring the unit from our warehouse in the USA, programming, testing, cleaning, etc.

Please note that this product has a maximum Lead Time

When you order this product, the "Lead Time" is the maximum time that takes us in business days before the product is shipped to you. This is for transferring from our warehouse (USA), programming (if applicable), preparing, cleaning, packing, etc.).

Of course, this is a maximum. It may, and usually does, take less than this time.

of 7 business days.

Engine Control Module (ECM/ECU) for 2001, 2002, and 2003 Toyota Highlander 2WD with the 1MZ-FE, 3.0L V6 engine with automatic transmission (A/T). This ECM was refurbished, reprogrammed, and tested. This ECM fits the Highlander models with no immobilizer.

TOYOTA PART# OF THIS ECM: 89661-48410

Exchangeable Part numbers that can be directly replaced with this ECM:

89661-48410
89661-48350
89661-48250
89661-48251
590-59564 (Hollander)
590-59309 (Hollander)
590-59035 (Hollander)

PROGRAMMING

This ECM is for the no-immobilizer models. No programming and no VIN are needed. Plug and Play. The transmission control circuit was also programmed to ensure a smooth shifting of automatic transmission.

WHY BUYING FROM US

We offer quality items that are backed up with a great warranty. These ECMs are offered in many marketplaces, but they are not tested, nor are programmed for your car. You will get the best value on these ECMs when you buy from us.

IDENTIFYING THE PART NUMBER

The part number of your ECM is located on the label at the top of the ECM as shown below. In tis example it is “89661-48410”

89661-48410 part number id med

Please, before ordering, always make sure your actual ECM part number matches any of the exchangeable part numbers listed further above on this page which are 100% compatible.

APPLICATIONS

List of vehicle models that this ECM will fit on:

2001 Toyota Highlander 3.0L, 6-Cylinders, 2WD, Automatic (A/T)
2002 Toyota Highlander 3.0L, 6-Cylinders, 2WD, Automatic (A/T)
2003 Toyota Highlander 3.0L, 6-Cylinders, 2WD, Automatic (A/T)

POSSIBLE SYMPTOMS

A bad ECM in the 2001-2003 Toyota Highlander may cause any of numerous symptoms, but the most common are:

The engine won’t start
Transmission harsh shifting problems
May give several error codes while all sensors check good
In some circumstances, will fix P0420 (most times, this problem is external to the ECM)

ECM LOCATION:

The 2001-2003 Toyota Highlander engine ECM is located under the right-hand dash area, below the glove compartment area as shown below.

2001-2003 toyota highlander ecm location

Notes referring to common questions we receive:

This is a direct replacement for the 2001-2003 Toyota Highlander ECM for the V6, 2WD, 3.0L models.
ECM (Engine Control Module) and ECU (Engine Control Unit) refers to the same part.
No programming is needed for starting the engine.
The warranty of this unit is specified at the top of this page.
We ship worldwide.
We ship through USPS and FedEx.
Shipping to the USA through USPS Priority Mail is FREE.
When installing, it is a good idea to disconnect the vehicle battery, but it is not a must.
No core charges. You do not need to send back your old ECM as a core.
This unit is the No-Security (No Immobilizer) version. This means that this is for the vehicles that do not use transponder keys (keys with a chip inside). If your vehicle uses the immobilizer system, you still may use this ECM but you will need to have it reprogrammed. You may also disconnect the immobilizer system as an alternative in order to use this ECM.

Images Disclaimer:

This is a refurbished product. It has been put back to factory functioning conditions and has been tested and made sure that it works as intended. In addition, a reasonable warranty has been included for the peace of mind of our customers.

The image(s) shown here is/are for reference and for identifying the product. The product you receive may vary slightly from the image shown here. Nevertheless, we always pick the best one we have available at the moment of shipping the order :)
